General information
Ex-Kabelverschraubung (Metall), gerade, M 75, 19 mm, OD min. 52.1
Ex-Kabelverschraubung (Metall), gerade, M 75, 19 mm, OD min. 52.1 - OD max. 62 mm, IP66, IP68 - 2,5 bar, Messing, vernickelt
Ordercode YESSS
6077-9516
Product code
1136700000
EAN code
4032248968206
Product group
Cable gland
Brand
WEIDMÜLLER
Serie
KSG (Klippon Standard Ex-Kabelverschraubung)
Type
KSG M75 BS O NI 2 G75S
Product description
Kabelverschraubung für den Einsatz in explosionsgefährdeten Bereichen (Ex e und Ex d). Die Verschraubung kann mit armierten oder nicht armierten Kabeln verwendet werden.
Product specifications
Material quality
Brass
Thread type
Metric
Nominal thread size metric/PG
75
Suitable for cable diameter
52.1 - 62 mm
With strain relief
Yes
Material
Metal
Degree of protection (IP)
IP66
Shock resistant
Yes
Halogen free
Yes
With locknut
No
Model
Straight
Bend radius protection/trumpet flare
Yes
Thread length
19 mm
Nominal thread size inch/gas pipe thread
Other
Pitch thread
1.5 mm
Wrench width
90 mm
Hexagon angular dimension
103.92 mm
RAL-number
7001
Surface protection
Nickel-plated
Glass-fibre reinforced
No
Colour
Silver
Multi seal area
No
Flat cable coupling
No
Type of sealing
Sealing ring
Separable screw gland
No
Working temperature
-60 - 180 °C
Explosion-tested version
Yes
For Ex-zone gas
1, 2
For Ex-zone dust
21, 22
For armoured cable
No
EMC-version
No
Screened
No
