General information
Ex-Kabelverschraubung (Metall), gerade, M 20, 16 mm, OD min. 7.2
Ex-Kabelverschraubung (Metall), gerade, M 20, 16 mm, OD min. 7.2 - OD max. 11.7 mm, IP66, IP68 - 2,5 bar, Messing
Ordercode YESSS
6077-9518
Product code
1136720000
EAN code
4032248968183
Product group
Cable gland
Brand
WEIDMÜLLER
Serie
KSG (Klippon Standard Ex-Kabelverschraubung)
Type
KSG M20 BS O SC 2 G20S
Product description
Kabelverschraubung für den Einsatz in explosionsgefährdeten Bereichen (Ex e und Ex d). Die Verschraubung kann mit armierten oder nicht armierten Kabeln verwendet werden.
Product specifications
Material quality
Brass
Thread type
Metric
Nominal thread size metric/PG
20
Suitable for cable diameter
7.2 - 11.7 mm
With strain relief
Yes
Material
Metal
Degree of protection (IP)
IP66
Shock resistant
Yes
Halogen free
Yes
With locknut
No
Model
Straight
Bend radius protection/trumpet flare
Yes
Thread length
16 mm
Nominal thread size inch/gas pipe thread
Other
Pitch thread
1.5 mm
Wrench width
25 mm
Hexagon angular dimension
28.87 mm
RAL-number
2202
Surface protection
Untreated
Glass-fibre reinforced
No
Colour
Other
Multi seal area
No
Flat cable coupling
No
Type of sealing
Sealing ring
Separable screw gland
No
Working temperature
-60 - 180 °C
Explosion-tested version
Yes
For Ex-zone gas
1, 2
For Ex-zone dust
21, 22
For armoured cable
No
EMC-version
No
Screened
No
