Ex-Kabelverschraubung (Metall), gerade, M 75, 19 mm, Einzeldrahtarmierung, 2.5 -
- 6077-9511
- |
- 1136650000
0
piece
in stock
Don’t have an account? Create one
-
Over 6.000 products in stock
-
Order before 17:00 and receive your order the next working day!
- Need help? Call --- --- or contact us via email at [email protected]
General information
Ex-Kabelverschraubung (Metall), gerade, M 75, 19 mm, Einzeldrahtarmierung, 2.5 -
Ex-Kabelverschraubung (Metall), gerade, M 75, 19 mm, Einzeldrahtarmierung, 2.5 - OD min. 71.1 - OD max. 78 mm, ID min. 60.50 - ID max. 68.00 mm, IP66,
Ordercode YESSS
6077-9511
Product code
1136650000
EAN code
4032248968091
Product group
Cable gland
Brand
WEIDMÜLLER
Type
KDSW M75 BS O NI 2 G75
Product description
Kabelverschraubung für den Einsatz in explosionsgefährdeten Bereichen (Ex e und Ex d). Die Verschraubung kann mit armierten oder nicht armierten Kabeln verwendet werden.
Product specifications
Material quality
Brass
Thread type
Metric
Nominal thread size metric/PG
75
Suitable for cable diameter
71.1 - 68 mm
With strain relief
Yes
Material
Metal
Degree of protection (IP)
IP54
Shock resistant
Yes
Halogen free
Yes
With locknut
No
Model
Straight
Bend radius protection/trumpet flare
Yes
Thread length
19 mm
Nominal thread size inch/gas pipe thread
Other
Pitch thread
1.5 mm
Wrench width
90 mm
Hexagon angular dimension
103.92 mm
RAL-number
7001
Surface protection
Nickel-plated
Glass-fibre reinforced
No
Colour
Silver
Multi seal area
No
Flat cable coupling
No
Type of sealing
Sealing ring
Separable screw gland
No
Working temperature
-60 - 180 °C
Explosion-tested version
Yes
For Ex-zone gas
1, 2
For Ex-zone dust
20, 21, 22
For armoured cable
Yes
EMC-version
No
Screened
Yes
