Panel PC WAGO

Add to selection
General information
Ordercode YESSS
6044-0073
Product code
762-5306/8000-002
EAN code
4066966056341
Product group
Panel PC
Brand
WAGO
Touch Panel 600 54.6 cm (21.5") 1920 x 1080 pixels Touch Panel 600 54.6 cm (21.5") 1920 x 1080 pixels
Product description

Touch Panel 600 54.6 cm (21.5") 1920 x 1080 pixels 2 x ETHERNET, 2 x USB, CAN, DI/DO, RS-232/485, Audio Control Panel

Product specifications
With hard disc
No
Max. main memory
4096 MByte
Preinstalled operating system
Linux
Type of display
TFT
With touch screen
Yes
Integrated keyboard
No
Supply voltage DC
24 - 24 V
Voltage type of supply voltage
DC
Number of HW-interfaces industrial Ethernet
2
Number of HW-interfaces RS-232
1
Number of HW-interfaces RS-485
1
Number of HW-interfaces USB
2
Number of HW-interfaces other
1
Supporting protocol for PROFIBUS
No
Supporting protocol for CAN
Yes
Supporting protocol for INTERBUS
No
Supporting protocol for ASI
No
Supporting protocol for KNX
No
Supporting protocol for MODBUS
Yes
Supporting protocol for Data-Highway
No
Supporting protocol for DeviceNet
No
IO link master
No
Supporting protocol for SUCONET
No
Supporting protocol for LON
No
Supporting protocol for PROFINET IO
No
Supporting protocol for PROFINET CBA
No
Supporting protocol for SERCOS
No
Supporting protocol for Foundation Fieldbus
No
Supporting protocol for EtherNet/IP
Yes
Supporting protocol for AS-Interface Safety at Work
No
Supporting protocol for DeviceNet Safety
No
Supporting protocol for INTERBUS-Safety
No
Supporting protocol for PROFIsafe
No
Supporting protocol for SafetyBUS p
No
Supporting protocol for other bus systems
Yes
Radio standard Bluetooth
No
Radio standard Wi-Fi 802.11
No
Radio standard GPRS
No
Radio standard GSM
No
Radio standard UMTS
No
Mouse-cursor control integrated
No
Degree of protection (IP), front side
IP65
Degree of protection (NEMA)
4
Operating temperature
0 - 45 °C
With floppy disc drive
No
With other storage media
Yes
Customer individual configuration
No
Number of free PCMCIA-slots
1
Rail mounting possible
No
Wall mounting/direct mounting
Yes
Front built-in possible
Yes
Rack-assembly possible
Yes
Mounting type, table foot
No
Mounting type, gallows mounting
No
Suitable for safety functions
No
Width of the front
554 mm
Height of the front
358 mm
Built-in depth
78 mm
Screen diagonal
21.5 inch
Number of pixels, horizontal
1920
Number of pixels, vertical
1080
more specifications
Product information
