Soft starter Eaton DS7
Add to selection
General information
Ordercode YESSS
0509-4535
Product code
134929
EAN code
4015081317448
Product group
Soft starter
Brand
Eaton
Serie
DS7
Type
DS7-342SX012N0-N
Softstarter, 12 A, 200 - 480 V AC, Us= 110
Softstarter, 12 A, 200 - 480 V AC, Us= 110 - 230 V AC, Baugröße FS1
Product description
Soft starter, Description: With internal bypass contacts, Function: Soft starters for three-phase loads, Mains supply voltage (50/60 Hz): ULN= 200 - 480 V AC, Supply voltage: Us= 110 - 230 V AC, Control voltage: UC= 110 - 230 V AC, Assigned motor rating (Standard connection, In-Line) at 400 V, 50 Hz: P= 5.5 kW, at 460 V, 60 Hz: P= 10 HP, Rated operational current AC-53: Ie= 12 A, Rated operational voltage: Ue= 200 V, 230 V, 400 V, 480 V, Connection to SmartWire-DT: no, Frame size: FS1, Standards: IEC/EN 60947-4-2, UL 508, CSA22.2-14
Product specifications
Rated operation current Ie at 40 °C Tu
12 A
Rated operating voltage Ue
230 - 480 V
Rated power three-phase motor, inline, at 230 V
3 kW
Rated control supply voltage at AC 50 Hz
110 - 230 V
Voltage type for actuating
AC
Rated power three-phase motor, inline, at 400 V
5.5 kW
Rated power three-phase motor, inside delta, at 230 V
0 kW
Function
Single direction
Internal bypass
Yes
Rated power three-phase motor, inside delta, at 400 V
0 kW
With display
No
Torque control
No
Rated surrounding temperature without derating
40 °C
Rated control supply voltage at AC 60 Hz
110 - 230 V
Rated control supply voltage at DC
0 - 0 V
Integrated motor overload protection
No
Release class
Other
Degree of protection (IP)
IP20
Degree of protection (NEMA)
1
