Motor protection circuit-breaker Schneider Electric TeSys GV2
Add to selection
General information
Ordercode YESSS
6032-6842
Product code
GV2LE14
EAN code
3389110516975
Product group
Motor protection circuit-breaker
Brand
Schneider Electric
Serie
TeSys GV2
Type
GV2LE14
Motorschutzschalter, 3p, 10A, magnetischer Auslöser, Kipphebel
Motorschutzschalter, 3p, 10A, magnetischer Auslöser, Kipphebel
Product description
Motorschutzschalter mit thermischer und magnetischer Auslösung Diese Geräte sind einfach zu bedienen und einzurichten, mit kompakten und ergonomischen Produkten für Anforderungen im Bereich von Startermotoren und Stop -Motoren.
Product specifications
Adjustment range undelayed short-circuit release
138 - 138 A
Rated operating voltage
690 - 690 V
With thermal overload protection
No
Device construction
Complete device in housing
Degree of protection (IP)
IP20
Rated short-circuit breaking capacity Icu at 400 V, AC
100 kA
Phase failure sensitive
Yes
Switch off technique
Magnetic
Rated permanent current Iu
10 A
Type of electrical connection of main circuit
Screw connection
Rated operation power at AC-3, 230 V
2.2 kW
Type of control element
Rocker lever
Rated operation power at AC-3, 400 V
4 kW
With integrated auxiliary switch
No
With integrated under voltage release
No
Number of poles
3
Height
89 mm
Width
45 mm
Depth
78.5 mm
