Cable connector Phoenix Contact
Add to selection
General information
Ordercode YESSS
6021-9283
Product code
1777992
EAN code
4017918039868
Product group
Cable connector
Brand
Phoenix Contact
PCB connector
PCB connector
Product description
PCB connector, nominal cross section: 2.5 mm², color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Female connector, number of potentials: 3, number of rows: 1, number of positions: 3, number of connections: 3, product range: MSTB 2,5/..-STF, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, conductor/PCB connection direction: 0 °, locking clip: - without locking clip, plug-in system: COMBICON MSTB 2,5, locking: Screw locking, mounting: Screw flange, type of packaging: packed in cardboard
Product specifications
Contact type
Bus
Number of poles
3
Modular spacing contacts
5.08 mm
Rated current In
12 A
Connectable conductor cross section fine-strand without cable end sleeve
0.2 - 2.5 mm²
Connectable conductor cross section solid-core
0.2 - 2.5 mm²
Material contact
Copper
Material insulation body
Other
Colour housing
Green
