General information
FAZ II 10/10 ZP BOLT ANCHOR
FAZ II 10/10 ZP BOLT ANCHOR
Ordercode YESSS
0140-4412
Product code
094981
Product group
Anchor bolt
Brand
Fischer
Serie
Bolzenanker FAZ II
Product description
The fischer bolt anchor FAZ II is the steel anchor for the most demanding requirements. Heavy loads are fixed into cracked concrete with the steel anchor. Due to the two anchorage depths and simple mounting, the FAZ II can be used in a particularly flexible manner. The proven expansion clip feeds the loads into the concrete in an especially secure manner and ensures maximum load-bearing properties. The zinc-plated steel version is used to fix loads in indoor areas. The steel anchor is, for example, suitable for fixing railings, cable trays and consoles.
Product specifications
Drill hole diameter
10 mm
Thread type
Metric
Thread size (metric)
10
Bracing
Split anchor
Anchor model
External thread
Fastening provision
Nut
Material anchor
Steel
Surface protection anchor
Galvanic/electrolytic zinc plated
With collar
No
Length
95 mm
Fastening by expander tool
No
Push-through installation
Yes
Pre-positioned installation
Yes
Spaced installation
No
Max. clamping thickness
10 mm
Wrench width
17 mm
Number of nuts
1
Number of washers
1
