Single- and multi-pole terminal strip WAGO
Add to selection
General information
Ordercode YESSS
6044-3209
Product code
731-135
EAN code
4044918269810
Product group
Single- and multi-pole terminal strip
Brand
WAGO
Feedthrough terminal block Conductor/wire-wrap connection Plate thickn
Feedthrough terminal block Conductor/wire-wrap connection Plate thickn
Product description
Feedthrough terminal block Conductor/wire-wrap connection Plate thickness: 1.5 mm 2.5 mm² Pin spacing 5 mm 5-pole CAGE CLAMP® 2,50 mm² gray
Product specifications
Connectable conductor cross section fine-strand without cable end sleeve
0.08 - 2.5 mm²
Material insulation body
Thermoplastic
Mounting method
Other
Explosion-tested version 'Ex e'
No
Connectable conductor cross section fine-strand with cable end sleeve
0.25 - 1.5 mm²
Connectable conductor cross section solid-core
0.08 - 2.5 mm²
Connectable conductor cross section multi-wired
0.08 - 2.5 mm²
Rated current In
5 A
Rated voltage
320 V
Type of electrical connection 1
Spring clamp connection
Type of electrical connection 2
Spring clamp connection
Number of poles
5
Number of clamp positions per pole
1
Operating temperature
-60 - 105 °C
Inflammability class of insulation material according to with UL94
V0
Closing plate required
No
Colour
Grey
Transparent
No
Width
5 mm
Height
14.3 mm
Depth
15.5 mm
