Switch actuator for bus system Eaton xComfort
Add to selection
General information
Ordercode YESSS
0508-3124
Product code
172939
EAN code
4015081695270
Product group
Switch actuator for bus system
Brand
Eaton
Serie
xComfort
Type
CSAU-01/01-10IE
Schaltgerät 10A mit Eingang, Energiemessung
Schaltgerät 10A mit Eingang, Energiemessung
Product description
Small design Switching Actuator 230VAC/10A with local 230Vac input and Energy Measurement. Easy to use with existing wall switches, control lights in stairways and hallways, switch lights directly with Motion sensors and twilight switches. Small design for installation behind switches, retractive switches, Motion sensors, wall sockets or in junction boxes. Suitable for high switching performance to switch a variety of loads such as lighting, ventilation, heating, etc.. Like a standard Binary Input Device the local input can also be assigned to other devices to send switching signals.
Product specifications
Bus system KNX
No
Bus system KNX radio
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
xComfort
Mounting method
Flush mounted (plaster)
Radio frequent bidirectional
Yes
Width in number of modular spacings
3
Local operation/hand operation
Yes
With LED indication
Yes
Max. switching current
10 A
Max. switching power
2300 W
Suitable for C-load
Yes
Max. number of switching contacts
1
Output power
2300 W
Rated current
10 A
Rated operating voltage
230 - 230 V
Different phases connectable
No
With bus connection
Yes
Bus module detachable
Yes
Modular expandability
No
Degree of protection (IP)
IP20
Min. depth of built-in installation box
18 mm
Number of digital inputs
1
Max. switching power LED
0 W
Power consumption
0.25 W
Product information
