General information
Emergency stop/emergency switching off pushbutton, RMQ-Titan, Palm-tre
Emergency stop/emergency switching off pushbutton, RMQ-Titan, Palm-tre
Ordercode YESSS
0508-5101
Product code
121460
EAN code
04015081192809
Product group
Front element for mushroom push-button
Brand
Eaton
Serie
RMQ M22
Type
M22-PVLT45P
Product description
Emergency stop/emergency switching off pushbutton, Product range: RMQ-Titan, Single unit, Design: Palm-tree shape, Diameter: 45 mm, Illumination: Illuminated with LED element, Turn-to-release function, Description: Tamper-proof according to ISO 13850/EN 418, Color Mushroom head: Red, Color Base: yellow, RAL 3000, Degree of Protection: IP66, IP67, IP69K, Connection to SmartWire-DT: no, Instructions: Max. number of contacts: four M22-(C)K01, …10 or two M22-(C)K02, …20, …11, Standards: IEC/EN 60947, VDE 0660
Product specifications
Colour button
Red
Degree of protection (IP)
IP67/IP69K
Switching function latching
Yes
Spring-return
No
Suitable for emergency stop
Yes
Construction type lens
Round
Diameter cap
45 mm
Hole diameter
22.5 mm
Degree of protection (NEMA)
4X
Width opening
0 mm
Height opening
0 mm
Type of button
High
Suitable for lighting
Yes
With front ring
No
Material front ring
Other
Colour front ring
Other
Unlocking method
Turn-release
With lighting
No
Supply voltage lamp
0 V
