End switch Eaton LS Eindschakelaars
Add to selection
General information
Ordercode YESSS
0508-9488
Product code
106778
EAN code
4015081065486
Product group
End switch
Brand
Eaton
Serie
LS Eindschakelaars
Type
LS-S02-120AFT-ZBZ/X
Positionsschalter, 2Ö, Basis, Federkraftverriegelung
Positionsschalter, 2Ö, Basis, Federkraftverriegelung
Product description
Position switch, Basic function: Position switches, Safety position switches, Part group reference: LS…ZBZ/X, Product range: Basic units with spring-powered interlock (closed-circuit principle), Degree of Protection: IP65, Features: Basic device, expandable, Ambient temperature: -25 - +40 °C, Description: With interlock monitoring, with auxiliary release mechanism, Monitoring of door position: continuous, Contacts N/C = Normally closed: 2 NC, Notes: = safety function, by positive opening to IEC/EN 60947-5-1, Rated control voltage for magnetic drive: Us= 120 V 50/60 Hz V, Housing: Insulated material, Connection type: Screw terminal , Standards: IEC/EN 60947
Product specifications
Width sensor
60 mm
Diameter sensor
0 mm
Switching function
Slow-action switch
Output electronic
No
Housing according to norm
Other
Rated operation current Ie at AC-15, 24 V
6 A
Height of sensor
173 mm
Length of sensor
39 mm
Rated operation current Ie at AC-15, 125 V
6 A
Rated operation current Ie at AC-15, 230 V
6 A
Rated operation current Ie at DC-13, 24 V
3 A
Rated operation current Ie at DC-13, 125 V
0.8 A
Switching function latching
No
Rated operation current Ie at DC-13, 230 V
0.3 A
Forced opening
Yes
Number of safety auxiliary contacts
2
Number of contacts as normally closed contact
2
Number of contacts as normally open contact
0
Number of contacts as change-over contact
0
Type of interface
None
Type of interface for safety communication
None
Construction type housing
Cuboid
Material housing
Plastic
Coating housing
Other
Type of control element
None
Type of electric connection
Cable entry metrical
Alignment of the control element
Other
With status indication
No
Suitable for safety functions
Yes
Explosion safety category for gas
None
Explosion safety category for dust
None
Ambient temperature during operating
-25 - 70 °C
Degree of protection (IP)
IP65
Degree of protection (NEMA)
Other
