Auxiliary contact block Eaton DILM
Add to selection
General information
Ordercode YESSS
0509-1495
Product code
208283
EAN code
4015082082833
Product group
Auxiliary contact block
Brand
Eaton
Serie
DILM
Type
DILM820-XHI11V-SI
Hilfsschalterbaustein, 2-polig, Ith= 10 A, 1 SF, 1 ÖS, Seitenanbau,
Hilfsschalterbaustein, 2-polig, Ith= 10 A, 1 SF, 1 ÖS, Seitenanbau, Schraubklemmen, DILM250 - DILH2600
Product description
Auxiliary contact module, Function: for standard applications, 2 pole, Connection technique: Screw terminals, Rated operational current AC-15 220 V 230 V 240 V: Ie= 4 A, Rated operational current AC-15 380 V 400 V 415 V: Ie= 4 A, Rated operational current AC-15 380 V 400 V 500 V: Ie= 4 A, Contacts N/OE: NO early-make: 1 N/OE, Contacts NCL=NC late-break: 1 NCL, Mounting type: Side mounted, For use with: DILM250 - DILH2600, DILDC300 - DILDC600, Type: Side-mounting auxiliary contacts
Product specifications
Mounting method
Side mounting
Number of contacts as change-over contact
0
Number of contacts as normally open contact
1
Number of contacts as normally closed contact
1
Number of fault-signal switches
0
Type of electric connection
Screw connection
Model
Top mounting
Lamp holder
None
Rated operation current Ie at AC-15, 230 V
6 A
