General information
Ordercode YESSS
0539-8172
Product code
100LET
EAN code
5027590427791
Product group
HRC fuse
Brand
Eaton
Serie
Bussmann High Speed BS
Type
100A 240V AC BS88 FUSE
Sicherungseinsatz, superflink, 100 A, AC 240 V, DC 150 V,
Sicherungseinsatz, superflink, 100 A, AC 240 V, DC 150 V, 200 kA, BS88, 18 x 56 mm, aR, BS
Product description
Fuse, Fuse-link, high speed, 100 A, AC 240 V, DC 150 V, BS88, 18 x 56 mm, aR, BS, offset bolted tags, protection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters, BS88-4, IEC 60269-4, Breaking Capacity 200 kA, Optional accessories fuse-holder BH-0111
Product specifications
Fuse construction type according to IEC 60269
Other
Type of current
AC
Rated voltage AC
280 V
Rated voltage DC
150 V
Rated current
100 A
Utilization category according to IEC 60269
aR
Breaking capacity
200 kA
Colour code
None
Type of fuse status indicator
None
Power loss at rated current
10 W
Mounting holes
M6
Centre-to-centre distance of connections
41.5 mm
Fuse system according to IEC 60269
Other
