Printed circuit board terminal WAGO
Add to selection
General information
Ordercode YESSS
6044-8303
Product code
250-704
EAN code
4044918300926
Product group
Printed circuit board terminal
Brand
WAGO
Double-deck PCB terminal block push-button 1.5 mm² agate gray
Double-deck PCB terminal block push-button 1.5 mm² agate gray
Product description
Double-deck PCB terminal block push-button 1.5 mm² Pin spacing 5 mm 8-pole Push-in CAGE CLAMP® 1,50 mm² agate gray
Product specifications
Height
20.9 mm
Number of electrical connections
8
Number of levels
2
Modular spacing connections
5 mm
Angle PCB/conductor connection
45°/135° (downwards inclined)
Rated current In
10 A
Rated voltage
320 V
Rated surge voltage
4 kV
Overvoltage category
III
Pollution degree
2
Connection type conductor
Spring clamp connection
Connectable conductor cross section solid-core
0.5 - 1.5 mm²
Connectable conductor cross section fine-strand with cable end sleeve
0.5 - 1 mm²
Connectable conductor cross section fine-strand without cable end sleeve
0.75 - 1.5 mm²
Connectable conductor cross section multi-wired
0.5 - 1.5 mm²
Connection type PCB
Soldering connection
Material connection surface
Tin
Length pin
4 mm
Material insulation body
Thermoplastic
Housing colour
Grey
Operating temperature
-60 - 105 °C
Type of PCB fastening
Connecting contact
Type of fastening
Solder
Type of banding
None
