Downlight/spot/floodlight Dotlux
Add to selection
General information
Ordercode YESSS
6068-7530
Product code
5134-0FW100
EAN code
4260629149252
Product group
Downlight/spot/floodlight
Brand
Dotlux
DOTLUX LED-Einbaupanel SQUAREip54 225x225mm IP54 18W COLORselect
DOTLUX LED-Einbaupanel SQUAREip54 225x225mm IP54 18W COLORselect
Product description
COLORselect: 2 Lichtfarben in einer Leuchte. Für viele Anwendungsumgebungen die passende Lichtfarbe einstellbar. Extra flaches Design ermöglicht den Einsatz auch bei schwierigen Einbauplätzen Stabile Montageklammern sorgen für sicheren Halt Spritzwassergeschütztes Gehäusedesign
Product specifications
Suitable for built-in mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for traverse mounting
No
Suitable for pedestal/floor mounting
No
Suitable for light-track mounting
No
Suitable for clamp-mounting
Yes
With movement sensor
No
With light source
Yes
Housing colour
White
Suitable for low voltage cable system
No
With light sensor
No
With control gear
No
Colour temperature
3000 - 5700 K
Dimming 0-10 V
No
Dimming 1-10 V
Yes
Dimming DALI
Yes
Beam angle
> 80° - Extreme wide beam
Length
225 mm
Width
225 mm
Height/depth
36 mm
Voltage type
DC
Colour of light
Multi-coloured
Colour rendering index CRI
90-100
Protection class according to IEC 61140
II
Dimming Zigbee
Yes
Power factor
0.9
Colour consistency (McAdam ellipse)
SDCM6
Suitable for wall mounting
Yes
Dimming DALI-2
Yes
Beam angle adjustable
No
Built-in diameter
205 - 205 mm
Unified Glare Ratio (UGR)
0
Energy efficiency class of the light source according to EU regulation 2019/2015
Not required
Product information
